HT26 1.5mA 100mv Silicon Piezoresistive Pressure Sensor with Selectable Four-Color Silicone Wire

Name: HT26 15mA 100mv Silicon Piezoresistive Pressure Sensor with Selectable FourColor Silicone Wire
Brand: HT sensor
Price: 1 USD

Quality HT26 1.5mA 100mv Silicon Piezoresistive Pressure Sensor with Selectable Four-Color Silicone Wire wholesale

Brand Name : HT sensor

Model Number : HT26

Certification : RoHs,ISO9001

Place of Origin : Baoji，China

MOQ : 1

Price : Negotiable

Payment Terms : Western Union, L/C, T/T

Supply Ability : 5000PCS/Month

Delivery Time : 5-8 work days

Packaging Details : Standard Export Package

Material : 316L

Min Range : -100kpa

Max Range : 60MPa

Supply : 1.5mA

Output : 100mv+-30mv

Selectable : Four-color silicone wire or Gold-plated pin

Model : HT26

High : 11.2mm

oil : diffusion silicon

Thread : no

Contact Now

HT26 Diffused Silicon Pressure Sensor Piezoresistive Pressure Sensor

Introduction of silicon pressure sensor:
The core of the HT26 silicon piezoresistive pressure sensor is a highly stable diffused silicon element. It is a small profile, media compatible, piezoresistive silicon pressure sensor packaged in a 316L stainless steel housing. The HT26 compensated is offered in a weldable package or with avariety of threaded fittings such as 1/4 and 1/8NPT, 1/4BSP as well as custom process fittings.

Product Features of silicon pressure sensor:

1.Small profile
2.Employing thick-film circuits for temperature compensation and zero-point
correction
3. Outstanding reliability, repeatability, and stability
4. Height of 7mm, customizable

Applications of silicon pressure sensor:

1.Water and Wastewater Treatment: Monitoring levels in tanks, wells, and reservoirs.
2.Chemical Processing: Measuring levels of various chemicals in storage tanks.
3.Industrial Tanks: Suitable for fuel, oil, and other liquid level monitoring.

Electrical Data of silicon Pressure sensor

Supply:1.5mADC Input impedance:3KΩ~6KΩ
Output impedance:2.5KΩ~6KΩ Insulation resistance:≥100MΩ/50VDC
Insulation voltage:500VAC between the housing and electrical connection will not cause damage
Medium compatible: liquid, gas compatible with 316L stainless steel

Performance Specification of silicon Pressure sensor

Parameters		Range:0~10KPa,20KPa, 35 KPa,100 KPa,200 KPa,350 KPa, 700 KPa, 1MPa, 2MPa,3.5 MPa,7 MPa,10 MPa,20 MPa,40 MPa,60 MPa,100 MPa
Parameters		Typical	Max.	Units
Pressure Non-linearity		±0.15	±0.3	%F.S
Pressure Repeatability and Hysteresis		0.02	0.05	%F.S
Zero Output		0±1	0±2	mV
Span Output	≤20KPa	50±10	50±30	mV
Span Output	≥35 KPa	100±10	100±30	mV
Temperature Error-Zero	≤20KPa	±1	±2	%F.S
Temperature Error-Zero	≥35 KPa	±0.5	±1	%F.S
Temperature Error-Span	≤20KPa	±1	±2	%F.S
Temperature Error-Span	≥35 KPa	±0.5	±1	%F.S
Proof Pressure		3X Rated range or 120MPa, whichever is less		-------
Operating Temperature Range		-20~80		℃
Compensated Temperature Range		0~70, 0~50(Range≤20KPa)		℃
Storage Temperature Range		-40~125		℃

Note :Above parameter under condition:Supply: 1.5mA Temperature: 25℃

Electrical connection and compensation
